In the GYTC8Y cable, singlemode/multimode fibers are positioned in the loose tubes, while the loose tubes
strand together around metallic central strength member into a compact and circular cable core, and the water-blocking
materials are distributed into interstices of it. After a PSP/APL is applied around the cable core, this part of cable accompanied
with the stranded wires as the supporting part are completed with a PE sheath to be a figure-8 structure.
Cable Construction
| Fiber count | 2F-24F | ||||||
| Loose Tube | Material | PBT | Diameter | 2.8mm | |||
| Tube-filling | Material | Filling compound | |||||
| Water blocking system | Material | Water blocking tape / Filling gel | |||||
| Mental strength member | Material | Steel wire | Size | 1.4mm | |||
| Gallus | Material | PE | Size (h*w) |
1.5mm*1.0mm | |||
| Outer Sheath | Material | PE | Color | black | |||
| Diameter | 3.8*6.5-12 (±0.5)mm |
Thickness | 1.6±0.1mm | ||||
Fiber Color
| No. | 1 | 2 | 3 | 4 | 5 | 6 |
| Color |  |
 |
 |
 |
 |
|
| No. | 7 | 8 | 9 | 10 | 11 | 12 |
| Color |  |
 |
 |
 |
 |
 |
Tube Color
Cable mechanical and environment characteristics
| Tensile strength | Long term | 600N | |||||
| Short term | 1500N | ||||||
| Crush load | Long term | 300N/100mm | |||||
| Short term | 1000N/100mm | ||||||
| Bending radius | Dynamic | 20D | |||||
| Static | 10D | ||||||
| Installation Temperature | -10℃～+60℃ | ||||||
| Storage Temperature | -40℃～+70℃ | ||||||
Fiber characteristics
| Fiber type | Unit | SM G652D | MM 50/125 | MM 62.5/125 | |||
| Condition | mm | 1310/1550 | 850/1300 | 850/1300 | |||
| Attenuation | dB/km | ≤0.36/0.24 | ≤3.0/1.5 | ≤3.0/1.5 | |||
| Cladding diameter | um | 125±1 | 125±1 | 125±1 | |||
| Cladding non-circularity | % | ≤1.0 | ≤1.0 | ≤1.0 | |||
| Coating diameter | um | 242±7 | 242±7 | 242±7 | |||
Package
Packing material: Wooden drum.
Packing length: 2km per drum or customization.
